1. Press “menu” on remote control, select “system configuration” and press “ok”.
2. Enter 4-digit “access code”, default is “1234”.

Photobucket
3. Select “factory default” and press “ok”.
4. Enter 4-digit “access code”, default is “1234”.

Photobucket
5. A prompt will appear, “do you want to reset receiver?”, press “ok”.
6. The “welcome” prompt will appear, press “ok”.

Photobucket
7. The “LNB configuration” window will appear on the screen. Enter the following parameters and press “ok”.
              Antenna   -  2
              LNB Power -  Yes
      DisEqC/Tone Burst -  Disable
8. The “Add channels” window will appear, enter the following parameters under “Default 02” and press “ok”.
Frequency       -  12390000
Symbol Rate   -  25600
Polarization     -  14V
Search Type   -  Transport

Photobucket
9. Press “ok” to search channels. The message “Searching in process, please wait” will appear. After search is completed, press “back” on remote.
10. The “Add channels” window will appear again, under Satellite select  “Default 02” and enter the following parameters under “TP2”. Press “ok”.
                            Frequency    -  12430000
                            Symbol Rate -  25600
                            0/22 KHz     -  ON
                            Polarization   -  14V
                            Search Type  -  Transport

Photobucket
11. Press “back” on remote. The “Add channels” window will appear again, under Satellite select  “Default 02” and enter the following parameters under “TP3”. Press “ok” to save.
         Frequency    -  12430000
         Symbol Rate  -  25600
         0/22 KHz     -  ON
         Polarization -  14V
         Search Type  -  Transport
12. Press Exit to Finish.

Photobucket
